What Is the Ohm’s Law PhET Lab
The PhET Ohm’s Law simulation is an interactive, web‑based experiment that lets you build a simple circuit with a resistor, a battery, and a multimeter. You can drag components, change voltage, and watch current respond in real time.
The core idea
In practice, the lab asks you to verify the relationship V = IR (voltage equals current times resistance). You’ll record a series of voltage‑current pairs, plot them, and calculate the slope, which should equal the resistor’s resistance.
What the answer key actually contains
Most instructors provide a PDF or Google Doc titled “Ohm’s Law PhET Lab Answer Key.” Inside you’ll find:
- Sample data tables (voltage, current, calculated resistance)
- Expected graph shape (a straight line through the origin)
- Step‑by‑step calculations for the slope and percent error
- Sample written conclusions and discussion prompts
The key isn’t a cheat sheet; it’s a benchmark. It shows the numbers you should get if you follow the lab instructions correctly and use the default resistor value (usually 100 Ω).
Why It Matters
You might wonder, “Why do I need the answer key at all? I can just run the simulation and see the numbers myself.”
First, many teachers grade the process as much as the result. If your data looks wildly off, they’ll ask you to explain why. Knowing the expected range saves you from a night‑marish rewrite.
Second, physics is as much about interpretation as it is about raw numbers. Seeing the correct slope and error bars helps you understand measurement uncertainty, a concept that pops up in every lab you’ll ever take Not complicated — just consistent..
Finally, the answer key gives you a template for the write‑up. The short version is: you won’t waste time figuring out how to format tables or phrase your conclusion Small thing, real impact..
How It Works (or How to Do It)
Below is a step‑by‑step walkthrough of the PhET lab, from launching the simulation to checking your work against the answer key.
1. Launch the simulation
- Go to phet.colorado.edu and select “Ohm’s Law.”
- Choose “Interactive” mode (not “Intro”).
2. Set up the circuit
- Drag a battery onto the workspace.
- Add a resistor (the default is 100 Ω).
- Place a voltmeter across the resistor and an ammeter in series.
3. Record data
| Voltage (V) | Current (A) | Calculated R (Ω) |
|---|---|---|
| 1.010 | 100 | |
| 2.Consider this: 030 | 100 | |
| 4. So 0 | 0. 0 | 0.020 |
| 3.0 | 0.That said, 040 | 100 |
| 5. Consider this: 0 | 0. 0 | 0. |
Tip: The answer key uses these exact values. If you see a slight deviation (e.g., 0.0098 A at 1 V), that’s normal—just round to three significant figures Easy to understand, harder to ignore..
4. Plot the graph
- Open a spreadsheet, plot Voltage on the y‑axis and Current on the x‑axis.
- Add a linear trendline and display the equation.
You should get something like y = 100x with an R² of 1.00.
5. Calculate the slope (resistance)
Use the formula slope = ΔV/ΔI. That's why with the data above, ΔV = 5 V and ΔI = 0. 05 A, so slope = 100 Ω Small thing, real impact..
6. Compute percent error
If the lab handout says the resistor is 100 Ω, the percent error will be 0 % (or a tiny number like 0.2 % if you used measured values) That alone is useful..
7. Write the conclusion
The answer key typically includes a paragraph such as:
“The experimental resistance (100 Ω) matches the nominal resistor value within 0.Day to day, 2 %. The linear V‑I relationship confirms Ohm’s Law for this circuit. Small discrepancies arise from the multimeter’s internal resistance and rounding And that's really what it comes down to..
Common Mistakes / What Most People Get Wrong
Forgetting to zero the ammeter
If you start the simulation with the ammeter already reading a small offset, every current value will be high, and your calculated resistance will be low. The answer key assumes a zeroed meter Still holds up..
Using the wrong units
People often write current in milliamps but keep voltage in volts, then plug those numbers into V = IR without converting. The slope ends up 1000× too big Turns out it matters..
Plotting the axes backwards
The classic mix‑up: voltage on the x‑axis, current on the y‑axis. The trendline will still be straight, but the slope now represents conductance (1/R) instead of resistance, and the answer key won’t match.
Ignoring the “through the origin” rule
Ohm’s Law predicts a line that passes through (0, 0). If you force the trendline to have a y‑intercept, you’ll artificially inflate the resistance Most people skip this — try not to..
Skipping significant‑figure rules
Reporting a resistance of 100.00 Ω when your measurements only have three sig figs looks sloppy and can raise a red flag on the rubric.
Practical Tips / What Actually Works
-
Zero the meters every time – click the “reset” button before you start recording.
-
Stick to one unit system – keep current in amperes, voltage in volts, resistance in ohms Small thing, real impact..
-
Use the built‑in data table – PhET lets you export the voltage‑current pairs directly to a CSV. No manual transcription errors.
-
Check the trendline equation – most spreadsheet programs let you display the exact slope. Compare it to the answer key’s 100 Ω Simple as that..
-
Round only at the end – do all calculations with full precision, then round the final resistance to three sig figs.
-
Write a brief discussion of error sources – mention the internal resistance of the virtual ammeter, the discrete steps of the voltage slider, and any rounding you performed Small thing, real impact..
-
Save a screenshot of the graph – many instructors ask for visual proof that you actually plotted the data.
FAQ
Q: Do I have to use the 100 Ω resistor?
A: Most answer keys assume the default 100 Ω resistor. If you change it, recalculate the expected slope accordingly (R = ΔV/ΔI).
Q: My current values are slightly off from the key—should I worry?
A: Not really. A 1–2 % difference is typical due to rounding. Just note it in your discussion That's the whole idea..
Q: Can I copy the answer key word‑for‑word?
A: That defeats the purpose. Use it as a guide, but write your own observations.
Q: Why does the graph sometimes show a tiny y‑intercept?
A: The simulation adds a minuscule offset to mimic real‑world instrument error. It’s okay; ignore it when calculating the slope.
Q: Is there a way to get the answer key directly from PhET?
A: No. PhET provides the simulation, not the instructor’s key. Your teacher or textbook should supply it.
